JM71113HT
High Torque© (HT) retention knob, BT30, M12X1.75, 15°, Solid; replaces JM71113
| Category: | Retention Knobs |
| Thread Size: | M12X1.75 |
| Angle: | 15 |
| Knob Diameter: | 0.511 |
| L1 Length: | 0.7480 |
| L2 Length: | 0.945 |
| Flange Thickness: | 0.157 |
| Hole Diameter: | - |
| Neck Diameter: | 0.352 |
| Pilot Diameter: | 0.512 |
| Shoulder Diameter: | 0.665 |
| Wrench Flat Diameter: | 0.549 |
| Socket Part #: | RKW30D |
| Number: | JM71113HT |
| Country of Origin: | USA |
This knob is a replacement for the following parts:
| Manufacturer | Part Number |
| For Machines (see disclaimer)*: | Komo |
* Retention knobs are not interchangeable. Machines are only given as a reference, JMPP makes no guarantee this is the correct knob for your machine. Please call us at 1-800-322-7750 or email sales@jmperformanceproducts.com for knob identification help.
